2012 Aston Martin DB9 Volante (facelift 2012) Dimensions, Size & Specs

Production
Model Year:2012
Production Years:2012 - 2015 discontinued in 2015
1282 mm50.5 in4.2 ft
4720 mm185.8 in15.5 ft
Length
4720 mm185.8 in15.5 ft
Width
2061 mm81.1 in6.8 ft
Height
1282 mm50.5 in4.2 ft
Technical Details

Exterior Dimensions

Precise measurements of the 2012 Aston Martin DB9 Volante, engineered for optimal performance and comfort

Dimensions
Length:4720 mm185.8 in15.5 ft
Width (Opened Mirrors):2061 mm81.1 in6.8 ft
Height:1282 mm50.5 in4.2 ft
Weight Specifications
Curb Weight:1890 kg4167 lbs
Tire Specifications
Rims Sizes:8.5J x 20, 11J x 20
Tire Sizes:245/35 ZR20 (W:245 | H:35 | D:20)
295/30 ZR20 (W:295 | H:30 | D:20)
Useful Information

About 2012 Aston Martin DB9 Volante

The Aston Martin DB9 Volante (facelift 2012), produced between 2012 and 2015, is a striking luxury cabriolet known for its blend of elegance and performance. With a length of 4720 mm (185.8 inches) and a width of 2061 mm (81.1 inches) measured with opened mirrors, the DB9 Volante maintains a commanding road presence without sacrificing sleek, aerodynamic styling. Its height stands at a low 1282 mm (50.5 inches), enhancing the car’s sporty profile and contributing to a low center of gravity for improved handling. The curb weight of this grand touring convertible is 1890 kg (4167 lbs), courtesy of its robust construction and high-performance components, which balances agile driving dynamics with luxurious comfort. The vehicle rides on 20-inch rims, with a size configuration of 8.5J x 20 at the front and 11J x 20 at the rear, paired with high-performance tires sized 245/35 ZR20 (front) and 295/30 ZR20 (rear). These specifications ensure optimal traction and stability, especially important for a powerful convertible like the DB9 Volante. This facelift edition updated the DB9’s visual appeal and technology, preserving its classic British craftsmanship while integrating subtle enhancements. The Aston Martin DB9 Volante remains an iconic symbol of luxury motoring, combining breathtaking design, precise engineering, and the exhilaration of open-top driving.

Exceptional Features

2012 Aston Martin DB9 Volante Highlights

Discover the standout features that make the 2012 Aston Martin DB9 Volante a leader in its class

Engine Performance

Equipped with a 6.0-liter V12 engine producing 510 horsepower, delivering a powerful and smooth driving experience.

Convertible Soft Top

Features an improved lightweight fabric soft top that can be operated electronically in under 16 seconds, enhancing open-air driving.

Exterior Design

Refined and aggressive facelift including a new front grille, LED daytime running lights, and updated rear lights for a modern and sporty look.

Interior Luxury

Handcrafted interior with premium leather upholstery, carbon fiber trim options, and advanced infotainment system for comfort and style.

Handling and Suspension

Features an all-aluminum chassis with improved adaptive damping suspension for enhanced ride quality and dynamic handling.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Aston Martin DB9 Volante (2012 facelift) has an overall length of 4720 mm (185.8 inches), a width with mirrors opened of 2061 mm (81.1 inches), and a height of 1282 mm (50.5 inches). These dimensions contribute to its sleek and athletic profile as a luxury grand tourer convertible.

The DB9 Volante (2012 facelift) has a curb weight of 1890 kg (4167 lbs). This weight balances solid road presence with nimble handling. While it is on the heavier side for a convertible sports car, the chassis and suspension tuning, paired with its powerful V12 engine, ensure strong performance, stable high-speed behavior, and confident cornering without sacrificing refinement.

The 2012 facelift Aston Martin DB9 Volante comes fitted with 20-inch rims, specifically 8.5J x 20 at the front and 11J x 20 at the rear. The tire sizes are 245/35 ZR20 on the front and 295/30 ZR20 on the rear. This staggered setup supports enhanced grip and stability, emphasizing the car's sporty yet luxurious driving experience.

With a width of 2061 mm (81.1 inches) including mirrors, a length of 4720 mm (185.8 inches), and a height of 1282 mm (50.5 inches), the DB9 Volante fits comfortably within the dimensions of a standard garage. Most single-car garages designed around typical dimensions (around 2400 mm width by 5400 mm length) can accommodate the car, but care should be taken when folding or opening mirrors due to its wide stance.

Compared to the pre-facelift DB9 Volante produced from 2004 to 2012, the 2012 facelift model maintains very similar exterior dimensions with only minor styling refinements. The facelift did not significantly change length, width, or height, preserving the original's balanced proportions. However, updates improved aerodynamics and interior features for a more modern appeal without affecting spatial characteristics.

Compared to rivals such as the Ferrari California or the Bentley Continental GTC, the Aston Martin DB9 Volante (2012 facelift) has dimensions placed between these competitors. It is slightly longer and lower than the Ferrari California, with a comparable width, while generally being lighter than the Bentley Continental GTC. The DB9 Volante’s dimensions contribute to a more traditional grand tourer stance with a strong focus on balance between sporty elegance and comfort.

The DB9 Volante has a low roofline height of 1282 mm (50.5 inches), typical for a luxury convertible with an emphasis on styling and aerodynamics. While this might restrict headroom slightly compared to taller vehicles, the interior is designed to maximize space efficiently. The cabin offers a driver-focused layout with comfortable seating for two adults, making it ideal for spirited drives and grand touring rather than rear passenger transport or spacious cargo capacity.

As a convertible grand tourer, the DB9 Volante’s trunk space is modest but practical, especially with the folding soft top. With the roof up, there is approximately 172 liters (6.1 cubic feet) of luggage capacity, suitable for luggage or smaller items. When the roof is lowered, storage space reduces due to the soft top folding mechanism, though precise figures vary. This is typical of grand tourer convertibles prioritizing style and performance over large cargo volume.

The DB9 Volante’s width of 2061 mm (81.1 inches) including mirrors is wide compared to average passenger cars, reflecting its grand touring nature. This wider stance enhances road presence and cornering stability but may require more care when navigating narrow city streets or parking in tight spaces. Drivers accustomed to wider luxury sports cars will find it manageable, but it may be less convenient than smaller sports cars or sedans in congested urban environments.

The 2012 facelift introduced subtle but important design updates to the DB9 Volante, including revised front and rear bumpers, updated headlights and taillights, and improved aerodynamics. Engineering enhancements included a refreshed 6.0-liter V12 engine with better output and efficiency, updated suspension for enhanced ride and handling, and refined interior materials and technology. Together, these changes modernized the DB9 while preserving the classic Aston Martin elegance and grand touring capability.
