2016 Acura NSX II Coupe Dimensions, Size & Specs

Production
Model Year:2016
1214 mm47.8 in4.0 ft
4470 - 4531 mm176.0 - 178.4 in14.7 - 14.9 ft
1214 mm47.8 in4.0 ft
4470 - 4531 mm176.0 - 178.4 in14.7 - 14.9 ft
1214 mm47.8 in4.0 ft
2217 mm87.3 in7.3 ft
1214 mm47.8 in4.0 ft
2217 mm87.3 in7.3 ft
1214 mm47.8 in4.0 ft
4470 - 4531 mm176.0 - 178.4 in14.7 - 14.9 ft
1214 mm47.8 in4.0 ft
2217 mm87.3 in7.3 ft
1214 mm47.8 in4.0 ft
2217 mm87.3 in7.3 ft
Length
4470 - 4531 mm176.0 - 178.4 in14.7 - 14.9 ft
Width
2217 mm87.3 in7.3 ft
Height
1214 mm47.8 in4.0 ft
Trunk Capacity
110 liter3.9 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2016 Acura NSX II Coupe, engineered for optimal performance and comfort

Dimensions
Length:4470 - 4531 mm176.0 - 178.4 in14.7 - 14.9 ft
Width:2225 mm87.6 in7.3 ft
Width (Folded Mirrors):1939 mm76.3 in6.4 ft
Width (Opened Mirrors):2217 mm87.3 in7.3 ft
Height:1214 mm47.8 in4.0 ft
Ground Clearance:94 mm3.7 in0.3 ft
Trunk Capacity:110 liter3.9 cu ft
Weight Specifications
Curb Weight:1725 kg3803 lbs
Maximal permitted Weight:2040 kg4497 lbs
Tire Specifications
Rims Sizes:11J x 20, 8.5J x 19
Tire Sizes:305/30 ZR20 103Y (W:305 | H:30 | D:20)
245/35 ZR19 93Y (W:245 | H:35 | D:19)
305/30 R20 (W:305 | H:30 | D:20)
245/35 R19 (W:245 | H:35 | D:19)
Useful Information

About 2016 Acura NSX II Coupe

The Acura NSX II, produced between 2016 and 2022, represents the second generation of Acura's iconic hybrid sports coupe. This model blends cutting-edge performance with a sleek and aerodynamic design tailored for driving enthusiasts. The NSX II coupe measures between 4470 mm and 4531 mm (176 inches to 178 inches) in length, making it compact yet aggressive in stance. It has a width of 2225 mm (87.6 inches) with mirrors opened, or a narrower width of 1939 mm (76.3 inches) when the mirrors are folded, allowing for better maneuverability and parking ease in tight spaces. The vehicle’s height is a low 1214 mm (47.8 inches), emphasizing its sporty, low-profile appearance.

Weighing in at 1725 kg (3802 lbs) curb weight, and a maximum weight of 2040 kg (4497 lbs), the NSX II balances lightweight agility with the components necessary for its sophisticated hybrid powertrain. This weight supports enhanced stability and responsiveness on the road without compromising performance. Ground clearance is limited to 94 mm (3.7 inches), typical of high-performance sports cars, ensuring a low center of gravity for improved handling but requiring caution over uneven surfaces.

The NSX II rides on 20-inch and 19-inch rims sized 11J x 20 (front) and 8.5J x 19 (rear), equipped with high-performance tires measuring 305/30 ZR20 (rear) and 245/35 ZR19 (front), designed to optimize grip and driving dynamics. Despite its performance focus, the NSX offers a luggage capacity of 110 liters, suitable for essential gear and light travel.

Overall, the Acura NSX II combines advanced hybrid technology and aggressive styling with a compact and agile footprint. Its dimensions make it suitable for both spirited driving and everyday usability, standing out in the high-performance coupe segment for those seeking a balance of technology, style, and driving excellence.

Exceptional Features

2016 Acura NSX II Coupe Highlights

Discover the standout features that make the 2016 Acura NSX II Coupe a leader in its class

Hybrid Powertrain

The 2016 Acura NSX II features a sophisticated hybrid powertrain that combines a twin-turbocharged 3.5-liter V6 engine with three electric motors, delivering a combined output of 573 horsepower for exceptional performance and efficiency.

Sport Hybrid SH-AWD

The Sport Hybrid Super Handling All-Wheel Drive system integrates the electric motors with the engine to provide dynamic torque vectoring, enhancing handling, traction, and cornering stability.

Lightweight Construction

The car's body utilizes a multi-material space frame made from aluminum, carbon fiber, and high-strength steel, resulting in a lightweight yet rigid chassis that improves agility and crash safety.

Advanced Aerodynamics

The NSX II's design incorporates active aerodynamic features such as underbody airflow management and rear spoilers that adjust to optimize downforce and reduce drag at high speeds.

Modern Interior and Technology

Inside, the NSX II boasts a driver-focused cockpit with premium materials, dual high-resolution LCD displays, and advanced infotainment features designed for intuitive control and comfort.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Acura NSX II, produced from 2016 to 2022, has an overall length that varies between 4470 mm and 4531 mm (approximately 176 inches to 178.3 inches). This slight variation depends on specific model configurations and minor design updates throughout its production cycle. This length places the NSX II squarely in the sports coupe category, allowing for an aggressive and aerodynamic profile that emphasizes speed and precision handling.

The width of the Acura NSX II coupe is 2225 mm (about 87.6 inches) without considering mirror positions. When the side mirrors are folded, the width narrows significantly to 1939 mm (roughly 76.3 inches), making it easier to fit into tighter spaces such as narrow parking spots. With the mirrors opened in their regular driving position, the width measures 2217 mm (approx 87.3 inches), which is just marginally narrower than the body width without mirrors, maintaining a sleek and flush design for optimal aerodynamics.

The Acura NSX II stands at a height of 1214 mm (47.8 inches), making it a very low-profile sports car. This low height contributes to a lower center of gravity, which significantly improves handling, road grip, and stability at high speeds. The combination of height and sleek lines enhances aerodynamic efficiency, reducing drag and lift, consequently allowing the NSX II to maintain strong performance parameters on both road and track.

The Acura NSX II has a curb weight of approximately 1725 kg (around 3804 lbs), which reflects the vehicle's weight without passengers or cargo but with necessary operating consumables. The maximum weight rating, including passengers and cargo—the gross vehicle weight rating (GVWR)—is about 2040 kg (4497 lbs). This balance of weight is indicative of the NSX's use of advanced lightweight materials such as aluminum and composite to optimize power-to-weight ratio without compromising structural rigidity.

The Acura NSX II offers a modest luggage capacity of 110 liters (approximately 3.9 cubic feet). As a high-performance sports coupe, it prioritizes engine compartment placement and aerodynamic styling over large cargo space. The limited storage capacity is typical for this class of vehicle and is suitable for carrying small bags or essentials needed for short trips or track days.

The ride height, or ground clearance, of the Acura NSX II is just 94 mm (3.7 inches). This very low clearance improves downforce and vehicle stability at high speeds by keeping the chassis close to the road surface, but it does require caution when navigating over speed bumps, steep driveways, or rough terrain. The low ground clearance is typical of sports cars designed for precision handling and responsive dynamics.

The Acura NSX II can fit into most standard home garages, though some considerations are necessary. A typical home garage in North America measures about 2440 mm (8 feet) wide and about 4875 mm (16 feet) deep. With a width of 2225 mm (87.6 inches) excluding mirrors and a length up to 4531 mm (178.3 inches), the NSX fits comfortably within these dimensional constraints. When including side mirrors folded (1939 mm or 76.3 inches), parking in tighter garages or parking spaces is easier. However, garage users should always measure their garage doors and interior to ensure sufficient clearance for both door opening and walking space around the vehicle.

Compared to the original NSX (NSX I) produced from 1990 to 2005, the Acura NSX II is longer, wider, and lower. The NSX II's approximate length ranges from 4470 mm to 4531 mm (176 to 178.3 inches), whereas the NSX I was about 4360 mm (171.7 inches) long. The wider body of the NSX II at 2225 mm (87.6 inches) surpasses the NSX I's width of around 1825 mm (71.8 inches), offering a more aggressive stance and increased interior space. Performance-wise, the NSX II incorporates a hybrid powertrain with turbocharged V6 and electric motors, delivering a considerably higher combined horsepower output and advanced handling technologies compared to the naturally aspirated V6 of the NSX I. This evolution underscores the second generation’s focus on integrating cutting-edge technology with enhanced driving dynamics.

When compared to other iconic mid-engine sports cars, the Acura NSX II is generally wider than competitors like the Porsche 911 (992 generation) and Audi R8 (second generation). The NSX II width is 2225 mm (87.6 inches), exceeding the Porsche 911’s width of approximately 1852 mm (72.9 inches) excluding mirrors, and is also wider than the Audi R8, which measures about 1940 mm (76.4 inches) wide. In length, the NSX II (4470-4531 mm / 176-178.3 inches) is close to the Porsche 911 (about 4519 mm or 178 inches) and a bit shorter than the Audi R8 (approx 4434 mm / 174.6 inches). The NSX II’s low height of 1214 mm (47.8 inches) is also on par with these competitors, emphasizing its sporty and aerodynamic profile. This dimension spread makes the NSX II more imposing on the road while maintaining comparable agility and performance within the mid-engine sports coupe segment.

The Acura NSX II is equipped with staggered tire sizes optimized for performance and handling precision. It rides on 11J x 20 inch rims at the front and 8.5J x 19 inch rims at the rear. The tire setup is 305/30 ZR20 (103Y) in the front and 245/35 ZR19 (93Y) in the rear. This staggered wheel and tire combination enhances grip, cornering ability, and stability, allowing the NSX II’s hybrid powertrain and advanced suspension system to deliver responsive and confident handling. These wide, low-profile tires ensure maximum contact with the road surface, improving traction and overall driver control during spirited driving or track usage.
